docsvef.blogg.se - Blackmagic videohub cleanswitch 12x12

#BLACKMAGIC VIDEOHUB CLEANSWITCH 12X12 FOR MAC#
#BLACKMAGIC VIDEOHUB CLEANSWITCH 12X12 WINDOWS 10#
#BLACKMAGIC VIDEOHUB CLEANSWITCH 12X12 PRO#
#BLACKMAGIC VIDEOHUB CLEANSWITCH 12X12 PLUS#

Supports Blackmagic Smart Control and Blackmagic Master Control hardware panels, incl.

#BLACKMAGIC VIDEOHUB CLEANSWITCH 12X12 FOR MAC#

External control panel: includes Blackmagic Videohub software control panel for Mac and Windows.Built-in control panel: 12 buttons for local control of the video hub with 6 buttons and scroll wheel for menu control.SDI Metadata Support: Identification of video data according to SMPTE 352M.SDI Auto Switching: Automatically selects between SD-SDI, HD-SDI and 6G-SDI on each input.SDI colour accuracy: 10 bit 4:2:2 and 4:4:4.SDI audio sampling: Television standard sampling rate of 48 kHz and 24 bit.SDI compliance: SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 424M, SMPTE 425M Level A and B, ITU-R BT.656 and ITU-R BT.601.4K Video Standards: 4K DCI 23.98p, 4K DCI 24p, 4K DCI 25p.

2K Video Standards: 2K DCI 23.98p, 2K DCI 24p, 2K DCI 25p, 2K DCI 23.98PsF, 2K DCI 24PsF, 2K DCI 25PsF.

Supports multiple formats on the same router at.

SD video standards: 525i59.94 NTSC, 625i50 PAL Smart Videohub CleanSwitch supports 12 inputs and 12 outputs in virtually all SD, HD and Ultra HD video formats.

RS-422 router control: 1 x input for router switching control.

Ethernet: Router configuration via front panel LCD or RJ45 Ethernet The Blackmagic Design Smart Videohub CleanSwitch 12x12 is a 6G-SDI 12x12 video router with built in re-synchronizer in each input.

Simultaneous routing of 4K, HD and SD video.

Automatic detection of SD, HD or 6G SDI.

Reference input: Tri-Sync or Black Burst.

Re-sync of video inputs on all 12 inputs for clean switching.

SDI video outputs: 12 x 10-bit SD-SDI, HD-SDI and 6G-SDI.

SDI video inputs: 12 x 10-bit SD-SDI, HD-SDI and 6G-SDI.

Power supply: 100 - 240 V AC input (IEC power cable not included).

#BLACKMAGIC VIDEOHUB CLEANSWITCH 12X12 WINDOWS 10#

Operating systems: Mac 10.15 Catalina, Mac 11.1 Big Sur or higher, Windows 10 64-bit.

Includes button and knob routing on the front panel.

Supports multiple formats on the same router at the same time and switches between multiple formats that match the reference frame rate when switching between the same video standard.

Supports 12 inputs and 12 outputs in virtually all SD, HD and Ultra HD video formats.

Can be used as a 12-way re-synchroniser for automatic re-timing of SDI feeds.

With built-in re-synchronisers on all inputs allows clean switching between all video sources of the same video standard.

Blackmagic Videohub SDK and Ethernet Videohub Control Protocol included Compatible operating systems: Mac Monterey 12.0, Mac Ventura 13.0 or higher / Windows 10, 64-bit, Windows 11 Power supply: 1 integrated AC power supply for 100 - 240 V, 50/60 Hz (IEC connection cable not included) Power consumption: 27.5 W Dimensions: 482 (19") x 44.2 (1U) x 236.14 mm Weight: 3.

#BLACKMAGIC VIDEOHUB CLEANSWITCH 12X12 PRO#

Supports Videohub Smart Control Pro and Videohub Master Control Pro hardware control panels.

#BLACKMAGIC VIDEOHUB CLEANSWITCH 12X12 PLUS#

Blackmagic Design Videohub 20x20 12G latency-free router for any combination of SD, HD and Ultra HD video signals, simultaneously on the same router has twenty 12G SDI inputs, twenty 12G SDI outputs plus reference connections front panel LCD signal distribution can be specified directly at the touch of a button or using the large rotary control with SDI reclocking and external control via Ethernet, all SDI video standards up to 2160p/60 are supported connections: SDI video inputs: 20 SDI video outputs: 20 SDI rates: DVB-ASI, 270 Mbit, 1.5 G, 3 G, 6 G, 12 G SDI neutrality: on all SDI outputs Reference inputs: for tri-sync or black burst Ethernet: Supports 10/100/1000Base-T Computer interface: USB-C Controls: Built-in front panel: 24 buttons for local control of Videohub, 3 buttons and knobs for menu control, 2.2-inch colour display External control: Blackmagic Videohub software control panel for Mac and Windows included.
